Omron PLC module CJ1W-II101

The OmronCJ1W-II101 is a digital input module for Omron's CJ series programmable logic controllers (PLCs), primarily used for connecting and controlling expansion racks.

Product Introduction

Model Explanation

• CJ1W: Indicates that this module is a CPU rack expansion unit for the Omron CJ1 series PLC. The CJ series represents Omron's mid-sized, high-performance PLCs, compatible with the CS series and a widely used mainstream product line.

• II101: This is the module's specific model code.

• I: Stands for Input.

• I: The second letter may represent the type, typically DC input.

• 101: A specific specification code that defines the number of points, voltage, circuit type, etc.

Product Features

• This unit serves as an expansion I/O interface unit. It must be installed on the left side of the expansion rack and works with the CPU rack's I/O control unit (such as the CJ1W-IC101). It supports up to three expansion racks.

• Each expansion rack requires one module and connects to the main control unit via a CS1W-CN313/713 cable.

Application Scenarios

• Industrial Automation: For production line equipment control (such as motors and sensors) and process parameter monitoring (temperature, pressure, etc.)

• Robotic Control: Supports multi-axis motion control and integrates input filtering (adjustable from 0 to 32ms) for interference mitigation.

Sample Image

Omron PLC module CJ1W-II101

Omron PLC module CJ1W-II101
