The CRB2BW10-90SZ produced by Japan's SMC Corporation is a rotary cylinder designed for small-angle, high-precision swing. It has a rotation angle of 10° and can be fine-tuned. It is mainly suitable for precision manufacturing and electronics industries.
Below is a brief description of its related information and application scenarios.
Product Introduction
| Brand | SMC |
|---|---|
| Model | CRB2BW10-90SZ |
| Series | CRB2 Series |
| Type | Rack and Pinion Rotary Cylinder, Rotary Cylinder, Pneumatic Cylinder |
Product Features
Space-Saving: Compact design, occupies little space
High-Precision Fine Adjustment: 10° oscillation angle, suitable for applications requiring precise, small adjustments
Built-in Sensor: Includes a magnetic switch, saving time and costs
Comparison
| Features | CRB2BW10-90SZ | CRB2BW30-180S |
|---|---|---|
| Rotation Angle | 10° (Fine Adjustment) | 30° (Fine Adjustment) |
| Oscillation Range | Very small, suitable for fine adjustments | Small, for general direction switching |
| Magnetic switch | Includes one | Not included |
| Typical applications | Precision alignment, deflection correction, fine adjustment | Workpiece flipping, direction switching, general clamping angle |
Application Scenarios
Due to its relatively small adjustment angle, it is suitable for automation applications requiring fine adjustment.
Precision manufacturing and electronics industries
Material handling and packaging industries
Testing and measuring equipment
Specialized fixtures
Primarily used in the first application, precision manufacturing and electronics. While the other applications are also applicable, other lower-cost rotary cylinders can be used as alternatives.
SMC rotary cylinder CRB2BW10-90SZ
Japanese SMC rotary cylinder CRB2BW10-90SZ
