Japan SMC compact thin cylinder MQQTB16-20D

The SMC MQQTB16-20D is a compact, thin-profile cylinder manufactured by SMC Corporation of Japan. It utilizes a gap seal structure with low sliding resistance, making it suitable for low-speed operating conditions and high-precision output control applications that are difficult to achieve with conventional cylinders.

This model has a bore of 16mm, a stroke of 20mm, and a built-in magnet. Its core features include a compact structure and a flat profile, making it particularly suitable for short-stroke, high-frequency, light-load operations. It is a commonly used basic actuator in automation equipment.

Product Introduction

Product Features

1. Compact Structure: Ultra-thin design and low height make it suitable for installation in limited spaces.

2. Square Cylinder Body: Easily installed and secured, and the magnetic switch is easily installed and adjusted.

3. Double-Acting Drive: Controls piston extension and retraction via dual-side intake and exhaust, ensuring stable motion.

4. Short-Stroke Design: 20mm stroke is suitable for small-scale clamping, positioning, blocking, and pressing operations.

5. Position Detection: Built-in magnetic ring allows for installation of magnetic switches, providing position signal feedback and facilitating integration with control systems such as PLCs.

Application Scenarios

This product is widely used in automation equipment, electronic assembly, packaging machinery, and robotics. Typical applications include:

1. Clamping Device: For gripping small parts;

2. Valve Actuation: Controls the opening and closing of small valves;

3. Detection Trigger: Triggers micro switches or sensors;

4. Workpiece Push: Pushes or ejects parts;

5. Precise Positioning: Used for limiting and blocking workpieces on conveyors.

Sample Images

Japan SMC thin cylinder MQQTB16-20D

Japan SMC thin cylinder MQQTB16-20D
